3/4 view from across the tracks - the door on this side is 38" wide by 86" highRAILROAD SIGNALS of the U.S.
RELAY BOX
New Installation
On the CSX Main Line Between Baltimore and DC
Relay (St Denis) MD
All pictures taken on a beautifully clear day, Sunday 082805.
This is a new installation where signals did not exist before,
However, there is a CPL bridge further north (OK, east for the hardcore
railroaders), about 3/4 of a mile,
We'll have to see if it is coming down once this installation is complete.
Here are a few other things in the immediate area:
For pictures of the signal bridge, Click HERE
For pictures of HX tower, click HERE
For pictures of stop signs found here, click
HERE, for pix of the
speed limit signs, click
HERE
For pictures of the memorial to the builders of the B&O, click HERE
For a map of the area, click
HERE
The cabinet is an 8x10 housing, 103" high in the middle, 97" at the corners, and made completely from aluminum
3/4 view from across the tracks - the door on this side is 38" wide by 86" high
The door on this side is 27" wide, by 86" high
Detail of one of the three hinges for each door
The door handle and lock
3/4 view of the opposite side as the first photo
Two views of the COTS electrical boxes (commercial off the shelf)
Shot of the electrical connection box mounted on the signal bridge
